REST API Connector for Power BI In this article you will learn how to integrate REST API data in Power BI without coding in just a few clicks (live / bi-directional connection to REST API). REST API Connector can be used to extract and output JSON/XML/CSV/String data coming from REST API web service calls (Web URL).. Using REST API Connector you will be able to connect, read, and write data from within Power BI. Follow the steps below to see how we would accomplish that. Download Documentation The driver mentioned above is part of ODBC PowerPack which is a collection of high-performance Drivers for various API data source (i.e. REST API, JSON, XML, CSV, Amazon S3 and many more). Using familiar SQL query language you can make live connections and read/write data from API sources or JSON / XML / CSV Files inside SQL Server (T-SQL) or your favorite Reporting (i.e. Power BI, Tableau, Qlik, SSRS, MicroStrategy, Excel, MS Access), ETL Tools (i.e. Informatica, Talend, Pentaho, SSIS). You can also call our drivers from programming languages such as JAVA, C#, Python, PowerShell etc. If you are new to ODBC and ZappySys ODBC PowerPack then check the following links to get started. ODBC PowerPack - System Requirements and Installation Getting Started - Using ODBC PowerPack ODBC API Driver Help File

Connect to REST API in other apps Connect to REST API in SSIS Connect to REST API in SQL Server Connect to REST API in SSRS Connect to REST API in Informatica Connect to REST API in MS Access Connect to REST API in MS Excel Connect to REST API in SSAS Connect to REST API in C# Connect to REST API in Python Connect to REST API in JAVA Connect to REST API in Tableau Connect to REST API in SAP Crystal Reports Connect to REST API in Azure Data Factory (Pipeline) Connect to REST API in Azure Data Factory (SSIS) Connect to REST API in Talend Studio Connect to REST API in UiPath Connect to REST API in PowerShell Connect to REST API in ODBC

Video Tutorial - Integrate REST API data in Power BI

This video covers following and more so watch carefully. After watching this video follow the steps described in this article.

• How to download / install required driver for REST API integration in Power BI
• How to configure connection for REST API
• Features about API Driver (Authentication / Query Language / Examples / Driver UI)
• Using REST API Connection in Power BI

Create ODBC Data Source (DSN) based on ZappySys JSON Driver

If your API is JSON Type and responding the json string response, in that case using ZappySys JSON Driver we can make the JSON API call and parse the json string. Let's configure the API call in the JSON Driver

1. Install ZappySys ODBC PowerPack.

2. Open ODBC Data Sources (x64):


3. Create a User Data Source (User DSN) based on ZappySys JSON Driver




   You should create a System DSN (instead of a User DSN) if the client application is launched under a Windows System Account, e.g. as a Windows Service. If the client application is 32-bit (x86) running with a System DSN, use ODBC Data Sources (32-bit) instead of the 64-bit version.

4. Select Url or File and paste the following Url for this example OR you can load existing connection string as per this article.


   NOTE: Here for demo, We are using odata API, but you need to refer your own API documentation and based on that you need to use your own API URL and need to configure connection based on API Authentication type

   https://services.odata.org/V3/Northwind/Northwind.svc/Customers?$format=json

5. Now enter JSONPath expression in Array Filter textbox to extract only specific part of JSON file as below ($.value[*] will get content of value attribute from JSON document. Value attribute is array of JSON documents so we have to use [*] to indicate we want all records of that array)


   NOTE: Here, We are using our desired filter, but you need to select your desired filter based on your requirement.


   Click on Test Connection button to view whether the Test Connection is SUCCESSFUL or Not.
   $.value[*]


6. Once you configured a data source, you can preview data. Hit Preview tab, and use similar settings to preview data:


7. Click OK to finish creating the data source

8. That's it; we are done. In a few clicks we configured the call to JSON API using ZappySys JSON Connector.

Create ODBC Data Source (DSN) based on ZappySys XML Driver

In upper section we check how to make the JSON API call using JSON Driver and parse the json string response. Same way if your API is XML/SOAP Type and responding the xml string response, in that case using ZappySys XML Driver we can make the XML/SOAP API call and parse the xml string. Let's configure the API call in the XML Driver.

1. Install ZappySys ODBC PowerPack.

2. Open ODBC Data Sources (x64):


3. Create a User Data Source (User DSN) based on ZappySys XML Driver




   You should create a System DSN (instead of a User DSN) if the client application is launched under a Windows System Account, e.g. as a Windows Service. If the client application is 32-bit (x86) running with a System DSN, use ODBC Data Sources (32-bit) instead of the 64-bit version.

4. Select Url or File and paste the following Url for this example OR you can load existing connection string as per this article.


   NOTE: Here for demo, We are using odata API, but you need to refer your own API documentation and based on that you need to use your own API URL and need to configure connection based on API Authentication type

   https://services.odata.org/V3/Northwind/Northwind.svc/Customers

5. Now enter Path expression in Array Filter textbox to extract only specific part of XML file as below ($.feed.entry[*] will get content of entry attribute from XML document. Entry attribute is array of XML documents so we have to use [*] to indicate we want all records of that array)


   NOTE: Here, We are using our desired filter, but you need to select your desired filter based on your requirement.


   Click on Test Connection button to view whether the Test Connection is SUCCESSFUL or Not.
   $.feed.entry[*]


6. Once you configured a data source, you can preview data. Hit Preview tab, and use similar settings to preview data:


7. Click OK to finish creating the data source.

8. That's it; we are done. In a few clicks we configured the call to XML API using ZappySys XML Connector.

Create ODBC Data Source (DSN) based on ZappySys CSV Driver

In upper section we check how to make the XML/Soap API call using XML Driver and parse the xml string response. Same way if your API is CSV Type or want to parse the CSV file data, in that case using ZappySys CSV Driver we can make the API call or read the CSV file data.

1. Install ZappySys ODBC PowerPack.

2. Open ODBC Data Sources (x64):


3. Create a User Data Source (User DSN) based on ZappySys CSV Driver

   ZappySys CSV Driver


   You should create a System DSN (instead of a User DSN) if the client application is launched under a Windows System Account, e.g. as a Windows Service. If the client application is 32-bit (x86) running with a System DSN, use ODBC Data Sources (32-bit) instead of the 64-bit version.

4. Select Url or File.


   Read CSV API in Power BI

   • Paste the following Url. In this example, We are using Zip format CSV File URL, but you need to refer your CSV File/URL.

     https://zappysys.com/downloads/files/test/cust-1.csv.zip
     Click on Test Connection button to view whether the Test Connection is SUCCESSFUL or Not.

   Read CSV File in Power BI

   • You can use pass single file or multiple file path using wildcard pattern in path and you can use select single file by clicking [...] path button or multiple file using wildcard pattern in path.


     Note: If you want to operation with multiple files then use wild card pattern as below
     (when you use wild card pattern in source path then system will treat target path as folder regardless you end with slash)

     C:\SSIS\Test\reponse.csv (will read only single reponse.csv file)
     C:\SSIS\Test\j*.csv (all files starting with file name j)
     C:\SSIS\Test\*.csv (all files with .csv Extension and located under folder subfolder)


     Click on Test Connection button to view whether the Test Connection is SUCCESSFUL or Not.

5. Once you configured a data source, you can preview data. Hit Preview tab, and use similar settings to preview data:


6. Click OK to finish creating the data source

7. That's it; we are done. In a few clicks we configured the read the CSV data using ZappySys CSV Connector.

Read REST API data in Power BI using ODBC

Importing REST API data into Power BI from table or view

1. Once you open Power BI Desktop click Get Data to get data from ODBC:


2. A window opens, and then search for "odbc" to get data from ODBC data source:


3. Another window opens and asks to select a Data Source we already created. Choose RestApiDSN and continue:

   RestApiDSN



4. Most likely, you will be asked to authenticate to a newly created DSN. Just select Windows authentication option together with Use my current credentials option:

   RestApiDSN



5. Finally, you will be asked to select a table or view to get data from. Select one and load the data!


6. Finally, finally, use extracted data from REST API in a Power BI report:


Importing REST API data into Power BI using SQL query

If you wish to import REST API data from SQL query rather than a table then you can use advanced options during import steps (as below). After selecting DSN you can click on advanced options to see SQL Query editor.

RestApiDSN

                SELECT
                    ProductID,
                    ProductName,
                    SupplierID,
                    CategoryID,
                    QuantityPerUnit,
                    UnitPrice
                FROM _root_
                WHERE UnitPrice > 20


Using a full ODBC connection string

In the previous steps we used a very short format of ODBC connection string - a DSN. Yet sometimes you don't want a dependency on an ODBC data source (and an extra step). In those times, you can define a full connection string and skip creating an ODBC data source entirely. Let's see below how to accomplish that in the below steps:

1. Open ODBC data source configuration and click Copy settings:


   ZappySys API Driver - REST API

   REST API Connector can be used to extract and output JSON/XML/CSV/String data coming from REST API web service calls (Web URL).

   RestApiDSN


2. The window opens, telling us the connection string was successfully copied to the clipboard:
3. Then just paste the connection string into your script:
   RestApiDSN

   DRIVER={ZappySys JSON Driver};DataPath='http://services.odata.org/V3/Northwind/Northwind.svc/Products?$format=json';Filter='$.value[*]';RequestHeaders='Accept: application/json;odata=verbose'


4. You are good to go! The script will execute the same way as using a DSN.

Limitations of using a full connection string

Despite using a full ODBC connection string may be very convenient it comes with a limitation: it's length is limited to 1024 symbols (or sometimes more). It usually happens when API provider generates a very long Refresh Token when OAuth is at play. If you are using such a long ODBC connection string, you may get this error:

"Connection string exceeds maximum allowed length of 1024"

But there is a solution to this by storing the full connection string in a file. Follow the steps below to achieve this:

1. Open your ODBC data source.
2. Click Copy settings button to copy a full connection string (see the previous section on how to accomplish that).
3. Then create a new file, let's say, in C:\temp\odbc-connection-string.txt.
4. Continue by pasting the copied connection string into a newly created file and save it.
5. Finally, the last step! Just construct a shorter ODBC connection string using this format:

   DRIVER={ZappySys API Driver};SettingsFile=C:\temp\odbc-connection-string.txt

6. Our troubles are over! Now you should be able to use this connection string in Power BI with no problems.

Editing query for table in Power BI

There will be a time you need to change the initial query after importing data into Power BI. Don't worry, just right-click on your table and click Edit query menu item:

Using parameters in Power BI (dynamic query)

In the real world, many values of your REST / SOAP API call may be coming from parameters. If that's the case for you can try to edit script manually as below. In below example its calling SQL Query with POST method and passing some parameters. Notice below where paraAPIKey is Power BI Parameter (string type). You can use parameters anywhere in your script just like the normal variable.

To use a parameter in Power BI report, follow these simple steps:

1. Firstly, you need to Edit query of your table (see previous section)

2. Then just create a new parameter by clicking Manage Parameters dropdown, click New Parameter option, and use it in the query:


                               = Odbc.Query("dsn=RestApiDSN",
                                            "SELECT * FROM _root_
                                             WITH (SRC='http://my-api-provider.com/api/" & MyParameter & "/items')")




   Refer to Power Query M reference for more information on how to use its advanced features in your queries.

Using DirectQuery Option rather than Import

So far we have seen how to Import REST API data into Power BI but what if you have too much data and you dont want to import but link it. Power BI Offers very useful feature for this scenario. Its called DirectQuery Option. In this section we will explore how to use DirectQuery along with ZappySys Drivers.

Out of the box ZappySys Drivers wont work in ODBC Connection Mode so you have to use SQL Server Connection rather than ODBC if you wish to use Live data using DirectQuery option. See below step by step instructions to enable DirectQuery mode in Power BI for REST API data.

Basically we will use ZappySys Data Gateway its part of ODBC PowerPack. We will then use Linked Server in SQL Server to Link API Service and then we will issue OPENROWSET queries from Power BI to SQL Server and it will then call REST API via ZappySys Data Gateway.

1. First read this article carefully, How to query REST API API in SQL Server.
2. Once linked server is configured we are ready to issue API query in Power BI.
3. Click Get Data in Power BI, select SQL Server Database
4. Enter your server name and any database name
5. Select Mode as DirectQuery
6. Click on Advanced and enter query like below (we are assuming you have created REST API Data Source in Data Gateway and defined linked server (Change name below).

   SELECT * FROM OPENQUERY([REST_API_LINKED_SERVER], 'SELECT * FROM Customers')

   SELECT * FROM OPENQUERY([REST_API_LINKED_SERVER], 'SELECT * FROM Customers')




   DirectQuery option for Power BI (Read REST API Data Example using SQL Server Linked Server and ZappySys Data Gateway)

7. Click OK and Load data ... That's it. Now your REST API API data is linked rather than imported.

Publishing Power BI report to Power BI service

Here are the instructions on how to publish a Power BI report to Power BI service from Power BI Desktop application:

1. First of all, go to Power BI Desktop, open a Power BI report, and click Publish button:



2. Then select the Workspace you want to publish report to and hit Select button:



3. Finally, if everything went right, you will see a window indicating success:



   If you need to periodically refresh Power BI semantic model (dataset) to ensure data accuracy and up-to-dateness, you can accomplish that by using Microsoft On-premises data gateway. Proceed to the next section - Refreshing Power BI semantic model (dataset) using On-premises data gateway - and learn how to do that.

Refreshing Power BI semantic model (dataset) using On-premises data gateway

Power BI allows to refresh semantic models which are based on data sources that reside on-premises. This can be achieved using Microsoft On-premises data gateway. There are two types of On-premises gateways:

• Standard Mode
• Personal Mode

Standard Mode supports Power BI and other Microsoft Data Fabric services. It fits perfectly for Enterprise solutions as it installs as a Windows Service and also supports Direct Query feature.

Personal Mode, on the other hand, can be configured faster, but is designed more for home users (you cannot install it as a Windows Service and it does not support DirectQuery). You will find a detailed comparison in the link above.

We recommend to go with Personal Mode for a quick POC solution, but use Standard Mode in production environment.

Below you will find instructions on how to refresh semantic model using both types of gateways.

Refresh using On-premises data gateway (standard mode)

Here are the instructions on how to refresh a Power BI semantic model using On-premises data gateway (standard mode):

1. Go to Power BI My workspace, hover your mouse cursor on your semantic model and click Settings:



2. If you see this view, it means you have to install On-premises data gateway (standard mode):



3. Install On-premises data gateway (standard mode) and sign-in:


   Use the same email address you use when logging in into Power BI account.

4. Register a new gateway (or migrate an existing one):



5. If you are creating a new gateway, name your gateway, enter a Recovery key, and click Configure button:



6. Now, let's get back to your semantic model settings in Power BI portal. Refresh the page and you should see your newly created gateway. Click arrow icon and then click on Add to gateway link:

   ODBC{"connectionstring":"dsn=RestApiDSN"}



7. Once you do that, you will create a new gateway connection. Give it a name, set Authentication method, Privacy level, and click Create button:

   dsn=RestApiDSN


   In this example, we used the least restrictive Privacy level.

   If your connection uses a full connection string you may hit a length limitation when entering it into the field. To create the connection, you will need to shorten it manually. Check the section about the limitation of a full connection string on how to accomplish it.

   On-premises data gateway (personal mode) does not have this limitation.

8. Proceed by choosing the newly created connection:

   ODBC{"connectionstring":"dsn=RestApiDSN"}



9. Finally, you are at the final step where you can refresh the semantic model:



Refresh using On-premises data gateway (personal mode)

Here are the instructions on how to refresh a Power BI semantic model using On-premises data gateway (personal mode):

1. Go to Power BI My workspace, hover your mouse cursor on your semantic model and click Settings:



2. If you see this view, it means you have to install On-premises data gateway (personal mode):



3. Install On-premises data gateway (personal mode) and sign-in:


   Use the same email address you use when logging in into Power BI account.

4. Again, go to your semantic model Settings, expand Data source credentials, click Edit credentials, select Authentication method together with Privacy level, and then click Sign in button:

   dsn=RestApiDSN



5. Finally, you are ready to refresh your semantic model:



Configuring pagination in the REST API Driver

ZappySys REST API Driver equips users with powerful tools for seamless data extraction and management from REST APIs, leveraging advanced pagination methods for enhanced efficiency. These options are designed to handle various types of pagination structures commonly used in APIs. Below are the detailed descriptions of these options:

1. Page-based Pagination: This method works by retrieving data in fixed-size pages from the Rest API. It allows you to specify the page size and navigate through the results by requesting different page numbers, ensuring that you can access all the data in a structured manner.

2. Offset-based Pagination: With this approach, you can extract data by specifying the starting point or offset from which to begin retrieving data. It allows you to define the number of records to skip and fetch subsequent data accordingly, providing precise control over the data extraction process.

3. Cursor-based Pagination: This technique involves using a cursor or a marker that points to a specific position in the dataset. It enables you to retrieve data starting from the position indicated by the cursor and proceed to subsequent segments, ensuring that you capture all the relevant information without missing any records.

4. Token-based Pagination: In this method, a token serves as a unique identifier for a specific data segment. It allows you to access the next set of data by using the token provided in the response from the previous request. This ensures that you can systematically retrieve all the data segments without duplication or omission.

Utilizing these comprehensive pagination features in the ZappySys REST API Driver facilitates efficient data management and extraction from REST APIs, optimizing the integration and analysis of extensive datasets.

For more detailed steps, please refer to this link: How to do REST API Pagination in SSIS / ODBC Drivers

Authentication

ZappySys offers various authentication methods to securely access data from various sources. These authentication methods include OAuth, Basic Authentication, Token-based Authentication, and more, allowing users to connect to a wide range of data sources securely.

ZappySys Authentication is a robust system that facilitates secure access to data from a diverse range of sources. It includes a variety of authentication methods tailored to meet the specific requirements of different data platforms and services. These authentication methods may involve:

1. OAuth: ZappySys supports OAuth for authentication, which allows users to grant limited access to their data without revealing their credentials. It's commonly used for applications that require access to user account information.

2. Basic Authentication: This method involves sending a username and password with every request. ZappySys allows users to securely access data using this traditional authentication approach.

3. Token-based Authentication: ZappySys enables users to utilize tokens for authentication. This method involves exchanging a unique token with each request to authenticate the user's identity without revealing sensitive information.

By implementing these authentication methods, ZappySys ensures the secure and reliable retrieval of data from various sources, providing users with the necessary tools to access and integrate data securely and efficiently. For more comprehensive details on the authentication process, please refer to the official ZappySys documentation or reach out to their support team for further assistance.

For more details, please refer to this link: ZappySys Connections

Advanced topics

Create Custom Stored Procedure in ZappySys Driver

You can create procedures to encapsulate custom logic and then only pass handful parameters rather than long SQL to execute your API call.

Steps to create Custom Stored Procedure in ZappySys Driver. You can insert Placeholders anywhere inside Procedure Body. Read more about placeholders here

1. Go to Custom Objects Tab and Click on Add button and Select Add Procedure:


2. Enter the desired Procedure name and click on OK:


3. Select the created Stored Procedure and write the your desired stored procedure and Save it and it will create the custom stored procedure in the ZappySys Driver:
   Here is an example stored procedure for ZappySys Driver. You can insert Placeholders anywhere inside Procedure Body. Read more about placeholders here


   CREATE PROCEDURE [usp_get_orders]
       @fromdate = '<<yyyy-MM-dd,FUN_TODAY>>'
    AS
       SELECT * FROM Orders where OrderDate >= '<@fromdate>';





4. That's it now go to Preview Tab and Execute your Stored Procedure using Exec Command. In this example it will extract the orders from the date 1996-01-01:


   Exec usp_get_orders '1996-01-01';




5. Let's generate the SQL Server Query Code to make the API call using stored procedure. Go to Code Generator Tab, select language as SQL Server and click on Generate button the generate the code.
   As we already created the linked server for this Data Source, in that you just need to copy the Select Query and need to use the linked server name which we have apply on the place of [MY_API_SERVICE] placeholder.


   SELECT * FROM OPENQUERY([MY_API_SERVICE], 'EXEC usp_get_orders @fromdate=''1996-07-30''')




6. Now go to SQL served and execute that query and it will make the API call using stored procedure and provide you the response.


Create Custom Virtual Table in ZappySys Driver

ZappySys API Drivers support flexible Query language so you can override Default Properties you configured on Data Source such as URL, Body. This way you don't have to create multiple Data Sources if you like to read data from multiple EndPoints. However not every application support supplying custom SQL to driver so you can only select Table from list returned from driver.

If you're dealing with Microsoft Access and need to import data from an SQL query, it's important to note that Access doesn't allow direct import of SQL queries. Instead, you can create custom objects (Virtual Tables) to handle the import process.

Many applications like MS Access, Informatica Designer wont give you option to specify custom SQL when you import Objects. In such case Virtual Table is very useful. You can create many Virtual Tables on the same Data Source (e.g. If you have 50 URLs with slight variations you can create virtual tables with just URL as Parameter setting.

1. Go to Custom Objects Tab and Click on Add button and Select Add Table:


2. Enter the desired Table name and click on OK:


3. And it will open the New Query Window Click on Cancel to close that window and go to Custom Objects Tab.

4. Select the created table, Select Text Type AS SQL and write the your desired SQL Query and Save it and it will create the custom table in the ZappySys Driver:
   Here is an example SQL query for ZappySys Driver. You can insert Placeholders also. Read more about placeholders here


   SELECT
     "ShipCountry",
     "OrderID",
     "CustomerID",
     "EmployeeID",
     "OrderDate",
     "RequiredDate",
     "ShippedDate",
     "ShipVia",
     "Freight",
     "ShipName",
     "ShipAddress",
     "ShipCity",
     "ShipRegion",
     "ShipPostalCode"
   FROM "Orders"
   Where "ShipCountry"='USA'




5. That's it now go to Preview Tab and Execute your custom virtual table query. In this example it will extract the orders for the USA Shipping Country only:


   SELECT * FROM "vt__usa_orders_only"




6. Let's generate the SQL Server Query Code to make the API call using stored procedure. Go to Code Generator Tab, select language as SQL Server and click on Generate button the generate the code.
   As we already created the linked server for this Data Source, in that you just need to copy the Select Query and need to use the linked server name which we have apply on the place of [MY_API_SERVICE] placeholder.


   SELECT * FROM OPENQUERY([MY_API_SERVICE], 'EXEC [usp_get_orders] ''1996-01-01''')




7. Now go to SQL served and execute that query and it will make the API call using stored procedure and provide you the response.


Conclusion

In this article we discussed how to connect to REST API in Power BI and integrate data without any coding. Click here to Download REST API Connector for Power BI and try yourself see how easy it is. If you still have any question(s) then ask here or simply click on live chat icon below and ask our expert (see bottom-right corner of this page).

Download REST API Connector for Power BI Documentation

More integrations

Other application integration scenarios for REST API

SSIS

SQL Server

SSRS

Informatica

MS Access

MS Excel

SSAS

C#

Python

JAVA

Tableau

SAP Crystal Reports

Azure Data Factory (Pipeline)

Azure Data Factory (SSIS)

Talend Studio

UiPath

PowerShell

ODBC

Other connectors for Power BI

Amazon Ads

Amazon Selling Partner (SP-API)

Asana

Azure DevOps

Cosmos DB

DropBox

ElasticSearch

FastSpring

Google BigQuery

Google Calendar

Google Drive

Google Sheets

Hubspot

Jira

Mailchimp

ManagedEngine ServiceDesk Plus (Zoho)

OData

OneDrive

Outlook Mail (Office 365)

Power BI

ServiceNow

SharePoint Online

Shopify

Smartsheet

Stripe

YouTube

Zendesk

Zoho CRM

Zoho SalesIQ

Zoom

REST API

JSON

JSON File

XML

SOAP

XML File

JDBC-ODBC Bridge

Salesforce

CSV

Amazon S3 JSON File

Amazon S3 XML File

Amazon S3 CSV File

Azure Blob JSON File

Azure Blob XML File

Azure Blob CSV File

FTP/SFTP JSON File

FTP/SFTP XML File

FTP/SFTP CSV File

Build your own Custom API Connector

Download REST API Connector for Power BI Documentation

Common Searches:
