In the world of REST APIs you have to know how to authenticate, before using any API method. In this article we will cover a topic how to authenticate to an API with OAuth 2.0 technology using SSIS or ODBC Drivers. We are going to use OAuth Connection Manager SSIS component to achieve that, which is a part of ZappySys SSIS PowerPack. Concepts listed in this articles also applicable for ODBC PowerPack product. If you like to access API data in BI Tools (e.g. Power BI, Excel, MS Access) or SQL Server directly then use ODBC PowerPack

Concepts about OAuth 2.0

In this post we will not cover in depth about OAuth 2.0 protocol. If you want to learn how OAuth 2.0 Protocol works then check article like this (or few more you can search). Don’t get overwhelmed by details 🙂 because you don’t have to worry when you use SSIS OAuth Connection Manager. Most of complexity of OAuth Protocol such as Token Extract, Token Renew is taken care by connection manager behind the scene for you.

Important things you will have to do to Call API in SSIS using OAuth are listed below.

1. Register OAuth App to obtain ClientID / Client Secret
2. Confirm OAuth 2.0 Grant Type (By default it will be Authorization Code Grant (i.e. 3-legged grant – Which shows Login Page when you click Generate Token Button). If you see mention about Grant Type=Client Credentials or Password Grant on your API help file then on you must configure SSIS OAuth Connection Manager with OAuth Version=2.0 and Change OAuth Grant Type drop down on the UI to correct setting. Refresh Token is only supported in Authorization Code Grant.
3. Obtain necessary Token URL (i.e. Token endpoint(s) – Usually documented in your API helpfile. Example : https://somesite/oauth/token )
4. Optional – Identify Scopes (i.e. Permission you want to grant to the token. Many times its not needed)
5. Optional – Identify redirect URL (Usually entered on App registration Page.. Same URL must be entered on the SSIS OAuth Connection Manager > Advanced Tab)

Video Tutorial

Grant Types in OAuth 2.0

There are multiple Grant Types in OAuth. API may enforce one or other based on Security Level they want to enforce. You can look at your API documentation to find out which Grant Type they are using. In above example of Hubspot API we used Authorization Code Grant (Its Default grant type in SSIS OAuth Connection Manager)

Authorization Code Grant Type

This is most common grant type for any popular API you may access (e.g. Google API, Facebook, LinkedIn ). In this grant type it requires 3-legged authorization for first time before you can obtain Access / Refresh Token.  Basically you will see Login Prompt for first time which you have to Accept before you can get token(s). After that you may not have to Log in again if you are using ZappySys SSIS OAuth Connection manager. Refreshing Token is automatica after first login call.

Client Credentials Grant Type

ZappySys offers various data integration components, including REST API Task, JSON Source, XML Source, and CSV Source, which allow you to connect to external APIs and retrieve data. For secure API authentication, you can create an OAuth connection using the Client Credentials Grant Type. Check this article to learn more about this option.

What is Client Credentials Grant Type?
The Client Credentials Grant Type is used by applications to access an API without user involvement. It is commonly used for machine-to-machine authentication, where the application itself authenticates with the API using a Client ID and Client Secret.

Steps to Create an OAuth2 Client Credentials Grant Type Connection

Calling API in SSIS using OAuth 2.0 – Client Credentials Grant Type

Password Grant Type

The Password Grant Type is an OAuth 2.0 flow used to exchange a user’s username and password directly for an access token. Depending on the API requirements, you may also need to provide a Client ID, Client Secret, and Scope. This flow is typically used in trusted applications or internal systems where collecting credentials directly is considered safe.

Steps to Create an OAuth2 Password Grant Type Connection

Calling API in SSIS using OAuth 2.0 – Password Grant Type

Understand AccessToken and RefreshTokens in OAuth 2.0

Along with GrantType there is one more concept in OAuth you have to understand. Its about two types of Tokens you get in OAuth 2.0

1. Access Token
2. Refresh Token

Here is brief description about each type of token.

Refresh Token

If you are using Authorization Code Grant Type (see previous section) then most API will send you RefreshToken and AccessToken after you finish 3-legged authorization first time (i.e. Login Dialog box). Refresh Token usually never expires. Some API may expire refresh tokens but after a long time (e.g. 90 days).  If you have case of expiring RefreshToken then you may have to use this Pattern

Access Token

Access Token is needed to call API and its usually short lived (expires in 1-2 hours).

If you are using Authorization Code Grant Type  then you have to use RefreshToken to get new AccessToken.

Step-by-Step – API Authentication with SSIS OAuth Connection

Now let’s look at an example of how to call API using SSIS OAuth Connection Manager and REST API Task. We will use HubSpot API as an example but concepts remain same for any other API such as Google API, Facebook, Twitter, LinkedIn

1. Login into the service provider (whose API you want to use) membership area.

   NOTE: Sometimes you have to create Developer account first and login using it.
2. Find API settings and create an application (API App). It will be your little bridge between user’s data and SSIS. Usually you will have to configure just a few fields:
   1. Name
   2. Scopes, your API App will be operating under
   3. Visibility
      E.g. for HubSpot, it looks like this:


      REST API App which will be used from within SSIS

      NOTE: Your API App will never go out of the defined scope.
3. Once you created an application, you should see fields Client ID and Client Secret nearby:


   Write down Client Id and Client Secret for the next step in OAuth authentication process

   NOTE: If you don’t see them right away, try accessing application settings and search them there.
4. Write down Client ID and Client Secret. We will need them later for authentication.
5. Open SSIS Designer and create a new package.
6. Right mouse click in the Connection Managers area and press New connection… and then ZS-OAUTH. This will create a new OAuth Connection.



   Create SSIS OAuth Connection for RESTful API authentication

7. Select OAuth Provider which will be used by an API when authenticating. Usually, OAuth Provider’s name is present in API’s name you want to use. E.g. Select

   Google

     as OAuth Provider for Google Sheets API:


   Select predefined OAuth Provider

   NOTE: If you can’t see the provider you want, you will have to use

   Custom

    option.
8. This step is optional (use it if you didn’t find predefined OAuth Provider). For custom OAuth Provider you will need to configure:
   1.  Authorization Url and Access Token Url, which you will find in a guideline of an API.
      For HubSpot API these look like this:


      Configure SSIS OAuth Connection Authorization and Access Token URLs

   2. Callback/Return Url, which you should have the same as Redirect Url field in you API App settings.
      For HubSpot API it is alright to enter your secure website address (with https). In this example, we will use

      https://zappysys.com/oauth

      .


      Set Callback/Return Url in OAuth Connection

      NOTE: Don’t be surprised you cannot find Redirect Url field in your API App configuration. Some OAuth Providers don’t use this option.
9. Now it’s time to supply Client Id and Client Secret you wrote down in Step #4, enter Scopes / Permissions your user will need (we will use

   contacts

   ) and Generate a Token:



   Input Client Id, Client Secret and Scopes to generate a token

   NOTE:

   • To add a scope for the predefined OAuth Provider, use Select Scopes button.
   • In scopes, if you set read only permissions you won’t be able call API methods that require write permissions.
   • Also be aware that you cannot use different scopes other than you defined in Step #2.
10. Login with user account whose data you wish to access or just select a user if no login is needed:


    Select the user, whose data you want to access

11. Grant user access to your API App:


    OAuth Connection SSIS component configuration – Grant access to HubSpot API App

12. You will get a prompt to save Access and Refresh tokens to a backup file. Press “Yes” to save them.

    NOTE: You will need to pass

    Refresh Token

     as the parameter, when you run the package in another machine. Check Deployment paragraph for more info.
13. That’s it! From now on your SSIS task/component via your API App will be able to use user’s data which you just granted access to.

Using System Default Browser to get the token

If embedded browser has some issue to extract your token then you can close the window by pressing [X] in the title bar. Once you do that you will be prompted to use System Default browser to finish the token extraction. If you click Yes then Full browser will be launched.

NOTE: Below feature is added in version published after Dec 31, 2019 (v3.0.0.11231 or later) so make sure you have latest version.

Using System Default Browser to extract OAuth Token

Untrusted App Warning

Sometimes Google might show you below warning. In order to continue the flow you might have to Click on Advanced and then click Go to YourAppName (unsafe) like below

How to ignore Google Unsafe App Warning (OAuth Flow)

Select the account

Using System Browser

Copy code and finish the flow

Manually Copy Code and Get OAuth Refresh / Access Token

Caching tokens (System-wide / multiple threads)

By default, each connection generates a new token. If you’re making repeated calls in a loop, you might notice that multiple tokens are created within a short time. To avoid this, you can enable token caching. This allows the same token to be reused across requests, significantly reducing the number of token renewal operations.

To cache token, perform the following steps

1. Goto the OAuth2 Grant Options Tab
2. Check the Cache token to file option
3. Enter Refresh Token / Cached Token File path. If the path is already prepopulated, then enter it where the token file will be saved.

Cache Token (Access token) – Across multiple processes and connections

Using OAuth 2.0 in ODBC Drivers / Data gateway

So in previous section we talked how to setup OAuth in SSIS. If you like to use similar setup for Drivers in  ODBC PowerPack then use below steps.

Following 3 drivers support OAuth Connection.

	Driver	Description
	JSON Files / REST API Driver Read More	Must have ODBC Driver for JSON Files / REST API / OData Integration Projects. It can be used to read data from local JSON Files or any JSON based API Services (such as Google Analytics, BigQuery, Office 365 and many more). It supports high performance JSON Streaming engine with many options such as Pagination, Error handling, Security, Filtering.
	XML Files / SOAP API Driver Read More	Must have ODBC Driver for XML Files / SOAP API / OData Integration Projects. It can be used to read data from local XML Files or any XML / SOAP based API Services (such as Google AdWords, DoubleClick, Salesforce and many more). It supports high performance JSON Streaming engine with many options such as Pagination, Error handling, Security, Filtering.
	CSV Files / REST API Driver Read More	Using this ODBC Driver you can read from CSV Formatted files or REST API which sends response in CSV format. It supports GZip or Zip format. If CSV data coming from URL you can use many advanced API settings such as Pagination, Error handling, Security.

ODBC Driver OAuth Setup

If you are using ZappySys ODBC Drivers for API integration then use below steps to configure OAuth Connection to call API.

1. Search for ODBC in start menu and select ODBC Data Source (64 bit)

2. Click ADD to Create a New ODBC DSN (Use System Tab if you creating DSN accessed by service account or other users on that machine)
3. Select desired ZappySys API driver (e.g. JSON Driver, XML Driver or CSV Driver)
4. When UI is visible like below you can select Connection Type dropdown to OAuth and click Configure.


   Configure OAuth Connection for ZappySys ODBC Drivers

Data Gateway OAuth Setup

If you are using Data Gateway for integration scenario like Import API data in SQL Server then use almost same steps as previous section (ODBC DSN Setup) but in this case we have to click on New Data Source on Gateway Config UI as below.

Configure Gateway Data Source

Parameterization and deployment to production

Conclusion

In this tutorial we learned how to access user’s data from within SSIS using an API by authenticating with OAuth 2.0. As you have probably noticed already, OAuth 2.0 was used not only for authentication, but for authorization too (remember the Scope you had to set?). In subsequent article you will really get your hands dirty (not really, it is actually simple) and learn how to call an API method using SSIS REST API Task.

Keywords

Connect to a RESTful API with OAuth using SSIS | How to authenticate to an API with OAuth using SSIS | Authenticate a user using OAuth with SSIS | Grant user access to API using OAuth from within SSIS | Authorize a user to access REST API with OAuth using SSIS

The post How to authenticate to an API with OAuth 2.0 using SSIS / ODBC appeared first on ZappySys Blog.

HubSpot is a popular platform where CRM, Marketing and Sales meet in one place. It’s a good piece of service, yet sometimes you need to integrate it with your other system. In this article you will learn how to pull contacts from HubSpot API and load them into a SQL Server Database using SSIS and ZappySys SSIS PowerPack.

Prerequisites

1. HubSpot Account registered (an account you will want to get data from).
2. SSIS designer installed. Sometimes it is referred as BIDS or SSDT (download it from Microsoft site).
3. Basic knowledge of SSIS package development using Microsoft SQL Server Integration Services.
4. An existing SQL Server Database and table created (we will use it to load data into).
5. ZappySys SSIS PowerPack installed.

Various methods to call HubSpot API

HubSpot API supports two kinds of authentication:

1. OAuth 2.0.
2. API Key in URL.

API Key in URL is simple, with minimal configuration, but it ought to be used only for development and testing purposes.

In this tutorial we will show how to authenticate using OAuth 2.0, which you should use in your production environment.

Step-by-Step – Get data from HubSpot API into SQL Server database

1. Create HubSpot Developer Account (https://app.hubspot.com/signup/developers). It’s an account you will need to use to create HubSpot Apps.
2. Login with your HubSpot Developer Account (https://app.hubspot.com/login).
3. Select your newly created HubSpot Developer Account:


   Logging into HubSpot – Select HubSpot developer account

   NOTE: Account name should contain “hubspot-developers” text.
4. Register HubSpot OAuth App for REST API Call for use with OAuth 2.0 by simply pressing “Create application” button:


   Register HubSpot OAuth App for REST API Call for use with OAuth 2.0

5. Name the application (e.g. “ContactsApp”) and choose “Private” to make the application hidden from the outer and dangerous world 🙂


   Name HubSpot REST API App which will be used from within SSIS

6. Press “Edit” button on the app you just created.
7. Write down Client ID and Client secret. We will need them later for authentication:


   Write down Client ID and Client Secret which will be used in OAuth Connection SSIS component

8. Open SSIS Designer and create a new package.
9. Drag a new Data Flow task from SSIS Toolbox into the Control Flow:



   Dragging and dropping Data Flow Task into Control Flow

10. Edit Data Flow task by double clicking. Then drag ZS JSON Source and OLE DB Destination components from SSIS Toolbox into the Data Flow, but don’t connect them yet:



    Drag ZappySys JSON Source SSIS component into the Data Flow

11. Start editing JSON Source component:
    1. Set Access Mode to File path or web URL.
    2. Set Web URL to

       https://api.hubapi.com/contacts/v1/lists/all/contacts/all?count=100

       .

       NOTE: We are adding URL parameter with value

       ?count=100

       , because by default HubSpot API returns 20 contacts and we want to maximize result set and minimize the number of web requests.
    3. Press Select Filter and select contacts node or simply enter

       $.contacts[*]

         into the text box.
    4. Check Use Credentials checkbox.
    5. Select <New ZS-OAUTH Connection> menu item to create a new connection:


       JSON Source SSIS component configuration – Get data from HubSpot API using OAuth authentication

12. Configure OAuth 2.0 connection for HubSpot API:
    1. Select HubSpot as OAuth Provider.
    2. Select “Use Custom OAuth (App created by you)” option.

       NOTE: You can also use Default OAuth App option for a quick test. Select it and press “Generate Token” button after you enter the scope.
    3. Paste Client Id and Client Secret you also saved in Step #7.
    4. Input

       contacts

        as our scope.
    5. Finally, press “Generate Token” button:


       OAuth Connection SSIS component configuration – Connect to HubSpot API using OAuth 2.0

13. Select your ordinary HubSpot account you want to get contacts from:


    OAuth Connection SSIS component configuration – Select a HubSpot account to get data from

    NOTE: Account name should NOT contain “hubspot-developers” text.
14. Grant access to your HubSpot App:


    OAuth Connection SSIS component configuration – Grant access to HubSpot API App

15. You will get a prompt to save Access and Refresh tokens to a backup file. Press “Yes” to save them.

    NOTE: You will need to pass

    Refresh Token

     as the parameter, when you run the package in another machine. Check Deployment to Production section for more info.
16. Configure HubSpot API pagination
    1. Set Next Link/Cursor Expression to

       $.vid-offset

         by pressing “…” button or simply pasting the value into the text box.
    2. In the same way set Stop Indicator/Attribute to

       $.has-more

       .
    3. Input

       false

        as Stop indicator value/Regular expression.
    4. Set Suffix for Next Url to

       &vidOffset=<%nextlink%>

       .


       JSON Source SSIS component pagination configuration for HubSpot API call

17. Press “Preview” button to… well, obviously to preview the results 🙂


    JSON Source SSIS component data preview of HubSpot API call result

18. Close “Data Preview” dialog and click “OK” button to save and close JSON Source component.
19. A dialog Metadata Scan Options should appear, to which you should respond “Ok” 🙂
20. Now you can connect JSON Source component with OLE DB Destination:



    Connect JSON Source SSIS component with OLE DB Destination for HubSpot data.

21. Now modify OLE DB Destination to have a connection to a SQL Server and point to a table, where you want contacts to be stored.
22. It’s time to map the columns of JSON Source with destination table columns. With your mouse simply connect corresponding columns or simply map Input Column with Destination Column. Press “OK” to close the window.


    Map JSON Source SSIS component columns with destination table columns you will store HubSpot data in

23. Finally, funtime! Press “F5” to execute the package. You should see a similar view as below. The number you see is the number of contacts were loaded from HubSpot API to your table:


    The result of getting HubSpot API data with SSIS

API Rate Limit (Throttling)

HubSpot places limits on using its API. Basically, it doesn’t allow you to make endless number of calls per second. Also it has a ceiling for requests made per day. So if you have paging enabled in JSON Source component, it will make as many requests as it has to retrieve all data. And in this step you may get an error, telling that you exceeded calling rate limit of the API. To avoid that, simply go to the Throttling tab and set the amount of milliseconds component has to sleep after making each call:

HubSpot API calls throttling configuration

Making things Dynamic (e.g. URL)

The URL we used (https://api.hubapi.com/contacts/v1/lists/all/contacts/all) in addition to

count

&showListMemberships=true

true

https://api.hubapi.com/contacts/v1/lists/all/contacts/all?showListMemberships={{User::ShowMemberships}}

Common Errors

For detailed instruction to fix common metadata related errors read this article.

Truncation related error

Most common error you may face when you run SSIS Package is truncation error. During design time only 300 rows scanned to detect datatype but at runtime you may extract far more records than 300. So its possible that you will get longer strings than initially expected. If you get error just copy that to notepad and read error carefully. It will explain the steps needed to fix the problem. Basically you can edit Columns on JSON Source UI > Change Data Length or Datatype (if you need more than 4000 chars change to the type to DT_NTEXT and click on Column Name cell to save change). After you edit default settings then make sure to check Lock option (found all on the right side in same row).

Authentication related error (happens when you run package from SQL Job Agent)

So many times when you run from Visual Studio it works fine but when you deploy to Production and run from SQL Job it fails. If this is your issue then check you passing Token (i.e. Password Property of HTTP connection) using some sort of parameter approach (e.g. from command line or from config file). By default password is encrypted using your account so when you run it from SQL Job it will fail to decrypt it. See more on Package Protection Level.

Deployment to Production

When you are ready to deploy the package to Production consider passing Refresh Tokens and other sensitive data as passwords via SSIS parameters. In this way you don’t face authentication related error described in above section. See more on Package Protection Level.

Download Sample Package

Be sure to download a sample SQL Server 2012 SSIS package, in case you encounter problems that you can’t go through in the step-by-step part.

Conclusion

In this article we learned how to call HubSpot API RESTful method and retrieve all contacts. Actually, HubSpot API consists of many small APIs and we used Contacts API method particularly. If you need anything else than simply retrieving the contacts of your account, delve into the vastness of HubSpot API methods!

Also it’s worth mentioning that JSON Source and OAuth Connection SSIS components saved us some valuable time, because we avoided using default SSIS Script Component and doing all the hard work ourselves.

Keywords

How to fetch data from HubSpot API | Pull data from HubSpot API into SQL Server | Call HubSpot API with SSIS | Sync HubSpot data to SQL Server | HubSpot data integration with SQL Server database | Load data from HubSpot REST API using SSIS

The post How to get data from HubSpot API with SSIS appeared first on ZappySys Blog.
